Single turns shaft potentiometers from Piher brand

New items have been added to Micros's offer, they are single turns shaft potentiometers ...

New items have been added to Micros's offer, they are single turns shaft potentiometers from Piher brand. They are made of polyester substrate, sealing IP54. Resistance range from 500R to 100kR.  Symbol of Micros Resistance Manufacturer part number  PO PC16sh0500 LIN 500R PC16SH10IP06501A2020TA PO PC16shk001 LIN 1kR PC16SH10IP06102A2020TA PO PC16shk002.5 LIN 2.5kR PC16SH10IP06252A2020TA PO PC16shk005 LIN 5kR PC16SH10IP06502A2020TA PO PC16shk010 LIN 10kR PC16SH10IP06103A2020TA PO PC16shk025 LIN 25kR PC16SH10IP06253A2020TA PO PC16shk100 LIN 100kR PC16SH10IP06104A2020TA PO PC16shk500 LIN 500kR PC16SH10IP06504A2020TA   Common parameters:  Potentiometer series: PC16 Potentiometer type: single turn Max. Operating voltage: 250VDC Body dimensions: Ø16 x 15.5mm Characteristics: linear Shaft diameter: 6mm Mounting: PCB

2017-02-23 read more
art

New WiFi and WiFi Bluetooth modules from ESPRESSIF

ESP-WROOM-02 and ESP-WROOM-32 are a cheap and functional WiFi modules...

ESP-WROOM-02 i ESP-WROOM-32 are a cheap and functional WiFi modules from ESPRESSIF.     ESP-WROOM-02 ESP-WROOM-32  Communications module type Wi-Fi Wi-Fi Bluetooth Transmitter output power: 20dB   Supply voltage: 3...3.6V DC 2,2 V do 3,6 V Receiver sensitivity: b: -91/-75/-72 dBm W: -90/-75/-70 dBm B: -98 dBm Supply current:  170/56mA 80mA Communictions protocol: FTP, HTTP, IEEE 802.11b/g/n, TCP/IP Ver. 4, UDP FTP, HTTP, IEEE 802.11b/g/n, TCP/IP Ver. 4, UDP Bluetooth: Bluetooth v4.2 / Bluetooth BLE Dimensions:  18 x 20 x 3mm 20 x 18 x 3 mm Ciphering: AES, WPA, WPA2, WPS  WEP, WPA/WPA2, PSK/Enterprise, AES / SHA2 / Elliptical Curve Cryptography / RSA-4096   Band:  2,412-2,484GHz od 2,412 GHz- 2,484 GHz Mounting: SMD SMD Chip: ESP8266, ESP32 WiFi standard: 802.11 b/g/n 802.11 b/g/n Additional features: - 18 terminals in the raster 2mm - Dual Core Tensilica LX6 240 MHz microcontroller, - SRAM 520 KB memory, - Flash memory: 16 MB - touch interface and integrated Hall sensor, - 32 terminals in the raster 1,27 mm,

2017-02-21 read more
art

ISO family of galvanic isolation circuits from Texas Instruments

A galvanic isolation is a technique that separates at least two circuits ...

A galvanic isolation is a technique that separates at least two circuits without allowing electricity to flow directly from one circuit to the other. The electricity is transferred between separated circuits in another form of energy. The main reasons for creating isolation are ensuring safety in harsh conditions (protection against electric shock) and reducing noise that passes through various parts of systems and devices. The most common form of galvanic isolation is the use of an opto-isolator. Digital isolators are replacing opto-isolators in many applications because they offer the same isolation capability while featuring better performance, higher data rate, less size and less power consumption. The ISO family of isolators from Texas Instruments employs capacitive coupling technique to transfer the signal across the isolation barrier. Our offer includes standard digital isolators of a different number of channels and different channel directionality and isolators integrated with interface circuits (CAN, I2C, RS-485) or IGBT/MOSFET gate driver. Part number Package UL 1577 isolation voltage Description, features Standard digital isolators ISO7140CCDBQ SSOP16 4200Vrms 4 channels (4/0), 50Mbps, 23ns ISO7221AD SOP08 2500Vrms 2 channels (1/1), 1Mbps, 405ns ISO7221CD SOP08 2500Vrms 2 channels (1/1), 25Mbps, 32ns ISO7231CDW SOP16W 2500Vrms 3 channels (2/1), 25Mbps, 32ns ISO7240CDW SOP16W 2500Vrms 4 channels (4/0), 25Mbps, 35ns ISO7241CDW SOP16W 2500Vrms 4 channels (3/1), 25Mbps, 35ns ISO7242CDW SOP16W 2500Vrms 4 channels (2/2), 25Mbps, 35ns ISO7421D SOP08 2500Vrms 2 channels (1/1), 1Mbps, 9ns ISO7421ED SOP08 2500Vrms 2 channels (1/1), 50Mbps, 7ns ISO7640FMDW SOP16W 4200Vrms 4 channels (4/0), 150Mbps, 7ns Isolated interface circuits ISO1050DUB SOP08(6.5mm) 4200Vrms CAN Transceiver, 1Mbps, TUV/CSA isolation voltage 2500Vrms ISO1050DW SOP16W 4200Vrms CAN Transceiver, 1Mbps, TUV/CSA isolation voltage 5000Vrms ISO1176DW SOP16W 2500Vrms RS-485 Transceiver, half-duplex, 40Mbps ISO3080DW SOP16W 2500Vrms RS-485 Transceiver, full-duplex, 0.2Mbps ISO3082DW SOP16W 2500Vrms RS-485 Transceiver, half-duplex, 0.2Mbps ISO3088DW SOP16W 2500Vrms RS-485 Transceiver, half-duplex, 20Mbps ISO1540D SOP08 2500Vrm Isolator compatible with I2C, 2 x bi-directional channel ISO1541D SOP08 2500Vrms Isolator compatible with I2C, 1x bi-directional + 1x uni-directional channel ISO5500DW SOP16W 4243Vrms IGBT/MOSFET gate driver, Vce/Ic 600V/150A max

2017-02-17 read more
art

Sensors by Freescale - NEW

Freescale offers a wide variety of pressure differential/gauge sensors. These MEMS ...

Freescale offers a wide variety of pressure differential/gauge sensors.   These MEMS-based pressure sensors provide robust solutions for the appliance, medical, consumer, industrial and automotive markets. They measure the difference in pressure between sources when pressure is applied to both sides of the sensor (differential) or the difference between source pressure and atmospheric pressure (gauged). These sensors combine advanced micromachining techniques, thin-film metallization and bipolar processing to provide an accurate analog output signal that is proportional to the applied pressure. Differential pressure sensors are available in uncompensated, compensated and integrated variations. Uncompensated pressure sensors are a basic series that are uncompensated and un-calibrated. Your system solution may need to be more involved to conduct the compensation for the sensor. However these sensors offer higher sensitivity, lower cost. Their low-level output allows flexibility of signal conditioning. Compensated pressure sensors are calibrated and temperature compensated. Many of the pressure sensors within the compensated series can be used for the medical market. They offer design advantages through their reduced device to device variations in offset and span and their reduced temperature drift in offset and span. Integrated pressure sensors are calibrated, temperature compensated and amplified. Since fewer external components are needed, the overall system design is simplified. Signal conditioning, calibration of span & offset and temperature compensation are included on-chip. Freescale offers a wide variety of vacuum (negative) pressure differential/gauge sensors. These sensors measure the difference in pressure between sources when pressure is applied to both sides of the sensor (differential) or the difference between source pressure and atmospheric pressure (gauged). These sensors are designed to measure positive and negative pressure. They are ideally suited for medical applications of all kinds. Freescale offers barometric air pressure (BAP) sensors that are calibrated, temperature compensated and amplified. Since fewer external components are needed, the overall system design is simplified. Barometric pressure sensors measure fluctuations in the pressure exerted by the atmosphere or air-fuel ratio in the engine of a vehicle to provide fuel efficiency. They generally measure absolute pressure where pressure is applied to the top of the die while the bottom of the die is a vacuum sealed reference.   Symbol Descriptions MPX10GP Pressure Sensor (Differential), 0÷10kPa, Vout 0÷35mV, 3÷6V, -40÷125°C MPX2010GSX Pressure Sensor (Gauge), 0÷10kPa, Vout 0÷25mV, 10÷16V, -40÷125°C MPX2102A Pressure Sensor (Absolute), 0÷100kPa, Vout 0÷40mV, 10÷16V, -40÷125°C MPX2202A Pressure Sensor (Absolute), 0÷200kPa, Vout 0÷40mV, 10÷16V, -40÷125°C MPX5100AP Pressure Sensor (Absolute), 15÷115kPa, Vout 0.2÷4.7V, 4.75÷5.25V, -40÷125°C MPXAZ6115AP Pressure Sensor (Absolute), 15÷115kPa, Vout 0.2÷4.7V, 4.75÷5.25V, -40÷125°C MPXH6300A6U Pressure Sensor (Absolute), 20÷304kPa, Vout 0.3÷4.9V, 4.74÷5.46V, -40÷125°C MPXH6300AC6U Pressure Sensor (Absolute), 20÷304kPa, Vout 0.3÷4.9V, 4.74÷5.46V, -40÷125°C MPXM2102as Pressure Sensor (Absolute), 0÷100kPa, Vout 0÷40mV, 10÷16V, -40÷125°C MPXV5010GC7U Pressure Sensor (Gauge), 0÷10kPa, Vout 0.2÷4.7V, 4.75÷5.25V, -40÷125°C MPX10DP Pressure Sensor (Differential), 0÷10kPa, Vout 0÷35mV, 3÷6V, -40÷125°C MPX4115AP Pressure Sensor (Absolute), 15÷115kPa, Vout 0.2÷4.8V, 4.85÷5.35V, -40÷125°C MPXHZ6250AC6T1 Pressure Sensor (Absolute), 20÷250kPa, Vout 0.3÷4.9V, 4.75÷5.25V, -40÷125°C MPXM2010GS Pressure Sensor (Gauge), 0÷10kPa, Vout 0÷25mV, 10÷16V, -40÷125°C MPXM2053GS Pressure Sensor (Gauge), 0÷50kPa, Vout 0÷40mV, 10÷16V, -40÷125°C MPXV4006DP Pressure Sensor (Differential), 0÷6kPa, Vout 0.2÷4.8V, 4.75÷5.25V, -10÷60°C MPXV5010GC6U Pressure Sensor (Gauge), 0÷10kPa, Vout 0.2÷4.7V, 4.75÷5.25V, -40÷125°C MPXV5050DP Pressure Sensor (Differential), 0÷10kPa, Vout 0.2÷4.7V, 4.75÷5.25V, -40÷125°C We recommend also other products by Freescale [Click]

2017-02-15 read more
art

LED controls from Polam-Elta Sp. z o. o.

We recommend news: LED controls from polish producer ...

POLAM-ELTA is polish producer of LED diodes and LED control lamps.  LED controls are used various segments of industry, f.e..as accesories of control cabinets, of control panels or  in machines.  Advantages of LED controls: small size, high luminous efficiency, energy savings, simple installation. We offer the following products:   Light colour Voltage OLB-D10-220V-DC blue 220VDC OLB-D10-230V-AC blue 230VAC OLB-D10-24V-AC/DC blue 24VAC/DC OLG-D10-220V-DC green 220VDC OLG-D10-230V-AC green 230V AC OLG-D10-24V-AC/DC  green 24VAC/DC OLO-D10-220V-DC orange 220VDC OLO-D10-230V-AC orange 230VAC OLO-D10-24V-AC/DC  orange 24VAC/DC OLR-D10-220V-DC red 220VDC OLR-D10-230V-AC red 230VAC OLR-D10-24V-AC/DC red 24VAC/DC OLW-D10-220V-DC   white 220V DC OLW-D10-230V-AC   white 230V AC OLW-D10-24V-AC/DC white 24VAC/DC OLY-D10-220V-DC yellow 220VDC OLY-D10-230V-AC yellow 230VAC OLY-D10-24V-AC/DC  yellow 24VAC/DC Concave Average hole. mounting: 13 mm Operating temperature: -40 ~ +70 Body: black Wires: 300 mm IP 44     Light colour Voltage OLB-D5-220V-DC blue 220V DC OLB-D5-230V-AC blue 230V AC OLB-D5-24V-AC/DC blue 24VAC/DC OLG-D5-220V-DC     green 220V DC OLG-D5-230V-AC     green 230V AC OLG-D5-24V-AC/DC   green 24VAC/DC OLO-D5-220V-DC   orange 220V DC OLO-D5-230V-AC   orange 230V AC OLO-D5-24V-AC/DC orange 24VAC/DC OLR-D5-220V-DC red 220V DC OLR-D5-230V-AC red 230V AC OLR-D5-24V-AC/DC red 24VAC/DC OLW-D5-220V-DC white 220V DC OLW-D5-230V-AC white 230V AC OLW-D5-24V-AC/DC  white 24V AC/DC OLY-D5-220V-DC yellow 220V DC OLY-D5-230V-AC yellow 230V AC OLY-D5-24V-AC/DC  yellow 24V AC/DC Concave Average hole. mounting: 11 mm Operating temperature: -40 ~ +70 Body: black Wires: 300 mm IP 44

2017-02-14 read more
art

Mounting potentiometers from ACP

Micros offers mounting potentiometers from the Spanish company ACP made ...

Micros offers mounting potentiometers from the Spanish company ACP made of carbon conductive path on the polyester substrate. High level of protection against dust IP54. We offer potentiometers in two sizes: 6 and 9, resistance range from 100R to 1MR, tolerance 20%, the orientation of the axis horizontal or vertical, operating temperature: -25~70°C  Symbol of Micros Resistance Potentiometer standard Potentiometer type Power Dimensions Pitch Mechanical rotation angle Torque Electrical rotation angle PO CA6hk001 1kR 6mm vertical 100mW 6.5x6.5x3.5mm 5x2.5mm 235 ±10° 0,2~2Ncm 215 ±20° PO CA6hk002.5 2.5kR 6mm vertical 100mW 6.5x6.5x3.5mm 5x2.5mm 235 ±10° 0,2~2Ncm 215 ±20° PO CA6hk005 5kR 6mm vertical 100mW 6.5x6.5x3.5mm 5x2.5mm 235 ±10° 0,2~2Ncm 215 ±20° PO CA6hk010 10kR 6mm vertical 100mW 6.5x6.5x3.5mm 5x2.5mm 235 ±10° 0,2~2Ncm 215 ±20° PO CA6hk025 25kR 6mm vertical 100mW 6.5x6.5x3.5mm 5x2.5mm 235 ±10° 0,2~2Ncm 215 ±20° PO CA6hk100 100kR 6mm vertical 100mW 6.5x6.5x3.5mm 5x2.5mm 235 ±10° 0,2~2Ncm 215 ±20°                     PO CA6v0500 500R 6mm horizontal 100mW 6.5x6.5x3.5mm 5x5mm 235 ±10° 0,2~2Ncm 215 ±20° PO CA6vk001 1kR 6mm horizontal 100mW 6.5x6.5x3.5mm 5x5mm 235 ±10° 0,2~2Ncm 215 ±20° PO CA6vk002.2 2.2kR 6mm horizontal 100mW 6.5x6.5x3.5mm 5x5mm 235 ±10° 0,2~2Ncm 215 ±20° PO CA6vk002.5 2.5kR 6mm horizontal 100mW 6.5x6.5x3.5mm 5x5mm 235 ±10° 0,2~2Ncm 215 ±20° PO CA6vk005 5kR 6mm horizontal 100mW 6.5x6.5x3.5mm 5x5mm 235 ±10° 0,2~2Ncm 215 ±20° PO CA6vk010 10kR 6mm horizontal 100mW 6.5x6.5x3.5mm 5x5mm 235 ±10° 0,2~2Ncm 215 ±20° PO CA6vk025 25kR 6mm horizontal 100mW 6.5x6.5x3.5mm 5x5mm 235 ±10° 0,2~2Ncm 215 ±20° PO CA6vk050 50kR 6mm horizontal 100mW 6.5x6.5x3.5mm 5x5mm 235 ±10° 0,2~2Ncm 215 ±20° PO CA6vk100 100kR 6mm horizontal 100mW 6.5x6.5x3.5mm 5x5mm 235 ±10° 0,2~2Ncm 215 ±20° PO CA6vk250 250kR 6mm horizontal 100mW 6.5x6.5x3.5mm 5x5mm 235 ±10° 0,2~2Ncm 215 ±20°

2017-02-03 read more
