Grässlin sensors and switches

2020-09-11

We recommend Grässlin products: among others motion detectors, electricity meters, time switches and presence detectors.

These are very high quality products. In addition, our employees provide technical support in product programming. CLICK HERE and see all products from Grässlin.

MOTION SENSORS:



Talis MW 180-12-1

Talis MW 240-16-1

Talis MWF2 200-9-1

Talis MWF3 200-9-1

Talis MFM 360-6-1

Dimensions (mm):

99 x 82,7 x 106,7

79 x 90 x 166

50 x 50 x 65,5

50 x 50 x 65,5

86,5 x 38 x 31,5

Voltage:

230V

230V

230V

230V

230V

Compliance of connections:
  • Load incandescent bulb:1.000 W
  • Load halogen lamp 500 W (AC)
  • Load fluorescent lamps 200 VA (not compensated)
  • Load LED lamp 150 W




  • Load incandescent bulb: 2.300 W
  • Load halogen lamp 1.000 W (AC) 1,000 VA / 600 W (LV conventional) 1,000 VA / 900 W (LV electronic)
  • Load fluorescent lamps 900 VA (compensated) 1.000 VA (not compensated) 600 W (not compensated)
  • Load energy-saving bulbs 400 W 600 VA CFL und PLL
  • Load LED lamp 400 W
  • Load incandescent bulb 5 - 300 W
  • Load halogen lamp 5 - 300 W (AC) 5 - 150 W (LV conventional) 5 - 150 W (LV electronic)
  • Load fluorescent lamps 5 - 150 VA
  • Load energy-saving bulbs 5 - 150 VA CFL und PLL
  • Load LED lamp 5 - 100 W
  • Supply voltage AC 230 V ± 10% 50-60 Hz
  • Load incandescent bulb 2.000 W
  • Load halogen lamp 1.000 W (AC) 1,000 VA / 600 W (LV conventional) 1,000 VA / 900 W (LV electronic)
  • Load fluorescent lamps 900 VA (compensated) 5 x 2 x 58 W 7 x 2 x 36 W 10 x 1 x 58 W 12 x 2 x 18 W 15 x 1 x 36 W 25 x 1 x 18 W
  • Load energy-saving bulbs 400 W 600 VA CFL und PLL
  • Load LED lamp 400 W
  • Load incandescent bulb 2.000 W
  • Load halogen lamp 1.000 W (AC) 1,000 VA / 600 W (LV conventional) 1,000 VA / 900 W (LV electronic)
  • Load fluorescent lamps 900 VA (compensated) 5 x 2 x 58 W 7 x 2 x 36 W 10 x 1 x 58 W 12 x 2 x 18 W 15 x 1 x 36 W 25 x 1 x 18 W
  • Load energy-saving bulbs 400 W 600 VA CFL und PLL
  • Load LED lamp 400 W

Power consumption:

1 V (in standby mode)

1 V (in standby mode) 1 V (in standby mode) 1 V (in standby mode)

<1W (w trybie czuwania)

Angle of detection:

do 180°

do 240° / 360°

do 200°

do 200°

do 360°

Range:

approx.12 m (At an installation height of 2 m

approx. 12 m (At an installation height of 2 m

approx. 9 m (At an installation height of 1.5 m,

approx. 9 m (At an installation height of 1.2-1,5 m)

approx. 5-11 m (At an installation height of 2,5 m

Time setting:

approx. 5sec. - 12 min.

approx. 5sec. - 30 min.

approx. 5sec. - 30 min.

approx. 5sec. - 30 min.

approx. 1min. - 15 min.

Channels no:

1

1

1

1

1

Temperature (operation):

-20°c do +45°

0°c do +45°

-20°c do +45°

0°c do +45°

0°c do +45°

Protection class:

II

II

II

II

II

Protection type:

IP 54

IP 55

IP40

IP 40

IP 44

Mounting:

surface mounted

surface mounted

flush mounting

flush mounting

installation in suspended ceiling

Application:

  • Stairwells
  • Building entrances and corridors
  • Reception areas and cellar rooms


ENERGY METERS:



Product type

Parameters

Taxxo E 100-3-MID

energy meters (digital) for DIN rail mounting
  • measurement of active energy
  • pulse output with 1000imp/1kWh resolution
  • minimum current 0. 25A, maximum 100A
  • 3-phase
  • single tariff
  • 7-module
  • 4-wire
  • possibility of sealing
  • 7-digit counter

Taxxo E 45-1-MID

energy meters (digital) for DIN rail mounting
  • measurement of active energy
  • pulse output with 1000imp/1kWh resolution
  • minimum current 0. 25A, maximum 45A
  • 1-phase
  • single tariff
  • 2-wire
  • possibility of sealing
  • 7-digit counter

Taxxo ER 80-1

energy meters (digital) for DIN rail mounting
  • measurement of active energy
  • pulse output with 1000imp/1kWh resolution
  • minimum current 0. 25A, maximum 80A
  • 1-phase
  • single tariff
  • 2-module
  • 2-wire
  • reset function
  • possibility of sealing
  • 7-digit counter
  • counter 2 x 6 digits

Taxxo M 45-1

energy meters (analog) for DIN rail mounting
  • measurement of active energy
  • pulse output with 1000imp/1kWh resolution
  • minimum current 0. 25A, maximum 45A
  • 1-phase
  • single tariff
  • 2-wire
  • possibility of sealing
  • 6-digit counter

APPLICATIONS

  • Electrical energy consumption measurement
  • Electrical heating facilities Installation in industrial or switching systems or other consumers of heavy current, power current, construction current and three-phase current
  • Office complexes
  • Camping and gardening facilities
  • Separate areas, e.g. in apartment buildings
  • Charging stations for electric cars
  • Shopping centres
  • Exhibition halls
  • Marinas Building services and wear monitoring for plants or machines


TIME SWITCHES FOR DIN RAIL MOUNTING:



Parameters

Talento Smart B15
  • 1 channel,
  • day program with date - 1, without date - 10
  • 100 memory locations
  • potential-free outputs
  • shortest switching time - 1 min
  • power reserve of 8 years
  • interface: Bluetooth 4.0

Talento Smart B25
  • 2 channels
  • day program with date - 1, without date - 10
  • 100 memory locations,
  • potential-free outputs
  • ON/OFF switching,
  • shortest switching time - 1 min
  • power reserve of 8 years
  • interface: Bluetooth 4.0

Talento Smart C15
  • 1 channel,
  • day program with date - 50, without date - 50
  • 500 memory locations,
  • potential-free outputs
  • shortest ON/OFF switching time - 1 min
  • PULSE, CYCLE, ASTRO, RANDOM switching
  • power reserve of 8 years
  • interface: Bluetooth 4.0

Talento Smart C25
  • 2 channels,
  • day program with date - 50, without date - 50
  • 500 memory locations,
  • potential-free outputs,
  • shortest ON/OFF switching time - 1 min
  • PULSE, CYCLE, ASTRO, RANDOM switching
  • power reserve of 8 years
  • interface: Bluetooth 4.0


PRESENCE SENSORS:



DO TALISII P360-10-1 HF

DO TALISII P360-10-2 HF

DO TALISII P360-20-1

DO TALISII P360-20-2

DO TALISII P360-24-1

DO TALISII P360-8-1

DO TALISII P360-8-2

DO TALISII PC40-5-1

DO TALISII PHB360-20-1

DO TALISII PS360-8-1

Dimensions (mm):

Ø80 x 70

Ø80 x 70

Ø82 x 104,4

Ø82 x 104,4

Ø105 x 66,5

Ø80 x 85

Ø80 x 85

Ø105 x 60

Ø105 x 66,5

Ø115 x 43

Voltage:

230V

230V

230V

230V

230V

230V

230V

230V

230V

230V

Compliance of connections:
  • Load incandescent bulb:200 W
  • Load halogen lamp (AC) max 1000W
  • Load fluorescent lamps 200 VA (not compensated)
  • Halogen (LV) amp load max. 900W
     (electronically) LED lamp max. 400W
  • Energy-saving lamp max. 400W
  • Load incandescent bulb:200 W
  • Load halogen lamp (AC) max 1000W
  • Load fluorescent lamps 200 VA (not compensated)
  • Halogen (LV) amp load max. 900W
    (electronically
    LED lamp max. 400W
  • Energy-saving lamp max. 400W
  • Load incandescent bulb:200 W
  • Load halogen lamp (AC) max 1000W
  • Load fluorescent lamps 200 VA (not compensated)
  • Halogen (LV) amp load max. 900W (electronically)
  • LED lamp max. 400W
  • Energy-saving lamp max. 400W
  • Load incandescent bulb:200 W
  • Load halogen lamp (AC) max 1000W
  • Load fluorescent lamps 200 VA (not compensated)
  • Halogen (LV) amp load max. 900W (electronically
  • LED lamp max. 400W
  • Energy-saving lamp max. 400W
  • Load incandescent bulb:2200 W
  • Load halogen lamp (AC) max 2200W
  • Load fluorescent lamps 1000 VA (not compensated)
  • LED lamp max. 600W
  • Energy-saving lamp max. 600W
  • Load incandescent bulb:2000 W
  • Load halogen lamp (AC) max 100W
  • Halogen (LV) lamp load max. 600W (traditional) Halogen (LV) lamp load max. 900W (electronically)
  • LED lamp max. 400W
  • Energy-saving lamp max. 400W
  • Incandescent lamp load max. 2000 W
  • Halogen (AC) lamp load max. 1000W
  • Halogen (LV) lamp load max. 600W (traditional) Halogen (LV) lamp load max. 900W (electronically)
  • LED lamp max. 400W
  • Energy-saving lamp max. 400W
  • Incandescent lamp load max. 2200 W
  • Halogen (AC) lamp load max. 2200W         Halogen (LV) lamp load max. 1000W (traditional)
  • LED lamp max. 600W
  • Energy-saving lamp max. 600W
  • Incandescent lamp load max.2200 W
  • Halogen (AC) lamp load max. 2200W
  • Halogen lamp load (LV) max. 1000W (traditional)
  • LED lamp max. 600W
  • Energy-saving lamp max. 600W
  • Incandescent lamp load max.2000 W
  • Halogen (AC) lamp load max. 1000W
  • Halogen lamp load (LV) max. 600W (traditional)
  • LED lamp max. 400W
  • Energy-saving lamp max. 400W

Power consumption

1 W (in standby mode)

 1 W (in standby mode) 1 W (in standby mode)

<1W (w trybie czuwania)

 1 W (in standby mode) 1 W (in standby mode) 1 W (in standby mode) 1 W (in standby mode) 1 W (in standby mode) 1 W (in standby mode)

Angle of detection

do 360°

do 360°

do 360°

do 360°

do 360°

do 360°

do 360°

do 360°

do 360°

do 360°

Range:

Ø10m (at an installation height of 2,5 m)

Ø10m (at an installation height of 2,5 m)

Ø20m (at an installation height of 2,5 m)

Ø20m (at an installation height of 2,5 m)

Ø25m (at an installation height of 2,5 m)

Ø8m (at an installation height of 2,5 m)

Ø8m (at an installation height of 2,5 m)

5 x40m (at an installation height of 2,5 m)

Ø20m (at an installation height of 2,5 m)

Ø8m (at an installation height of 2,5 m)

Time setting:

approx. 5sec. - 30 Min.

CH 1 ok, 5sec. - 30 Min. CH 2 ok 10sec, -60 Min.

approx. 5sec. - 30 Min..

CH1 ok, 5sec. - 30 Min..    CH2 ok. 10sec. -60min

approx 30sec. - 30 Min..

approx. 5sec. - 30 Min..

CH1 ok, 5sec. - 30 Min..  CH2 10sec, -60min

approx. 30sec. - 30 Min..

approx. 30sec. - 30 Min..

approx. 5sec. - 30 Min..

Channels no.:

1

1/2

1

1/2

1

1

1/2

1

1

1

Temperature (operation):

-20°c do +50°

-20°c do +50°

 0°c do +45°

0°c do +45°

-20°c do +45°

0°c do +45°

0°c do +45°

-20°c do +45°

-20°c do +45°

0°c do +45°

Protection class:

II

II

II

II

II

II

II

II

II

II

Protection type:

IP 54

IP 54

 IP 44

IP 44

IP 20, IP54 przy montażu natynkowym

IP 44

IP44

IP 20, IP54 przy montażu natynkowym

 IP 20, IP54 przy montażu natynkowym

IP 40

Mounting:

Installation in suspended ceiling

Installation in suspended ceiling

Installation in suspended ceiling

Installation in suspended ceiling

Flush mounting

Installation in suspended ceiling

Installation in suspended ceiling

Flush mounting

Flush mounting

Surface mounted
