RBS070410

RBS07 is a cost-effective mercury-free sensor designed to detect a 45° tilt over a full 360° range, as well as for detecting an "upside-down" position of an object. The sensor functions as a normally closed switch, with its contacts opening when the tilt reaches between 30° and 60°. It offers a durability of 100,000 electrical cycles and 1,000,000 mechanical cycles. The contact rating is 10mA/5VDC, with a contact impedance of 10Ω max, insulation resistance of 50MΩ min. @ 100VDC, and dielectric strength of 50VDC for 1 minute. It is produced in a package suitable for through-hole or surface mount installation, available in versions compatible with horizontally or vertically oriented PCBs.
