SMD Power Inductor; 47uH

Symbol Micros: D DER0705-047

120288

D DER0705-047

Contractor Symbol:

Case : Rys.DER0705

Datasheet

Technical drawing Add to favourites

SMD power inductor; inductance: 47uH; 20%; current: 0,85A; resistance: 0,156R; dimensions: 7.2x7.2x4.8mm; operating temperature: -40°C ~ 85°C

Parameters

Dimensions:	7.2x7.2x4.8mm
Inductance:	47uH
Inductor type:	Power
Manufacturer:	N/A
Mounting:	SMD
Current:	0,85A
Resistance:	0,156 Ohm

All parameters

Manufacturer:: PASSIVE TECH Manufacturer part number:   Case style: Rys.DER0705

In stock:

330 pcs.

Quantity of pcs.	2+	10+	50+	200+	1000+
Net price (EUR)	0,4597	0,2792	0,2140	0,1930	0,1837

Add to comparison tool Add inquiry (RFQ)

Packaging:
1000 Quantity (multiple: 1)

- +

Manufacturer:: PASSIVE TECH Manufacturer part number:   Case style: Rys.DER0705

In stock:

1000 pcs.

Quantity of pcs.	2+	10+	50+	200+	1000+
Net price (EUR)	0,4597	0,2792	0,2140	0,1930	0,1837

Add to comparison tool Add inquiry (RFQ)

Packaging:
1000 Quantity (multiple: 1)

- +

• Parameters

Dimensions:	7.2x7.2x4.8mm
Inductance:	47uH
Inductor type:	Power
Manufacturer:	N/A
Mounting:	SMD
Current:	0,85A
Resistance:	0,156 Ohm
Operating temperature (range):	-40°C ~ 85°C
Tolerance:	20%
