SMD Power Inductor; 100uH

Symbol Micros: D DL22-100

47419

D DL22-100

Contractor Symbol:

Case : Rys.DL22

Datasheet

Technical drawing Add to favourites

SMD power inductor; inductance: 100uH; 20%; current: 1.2A; resistance: 0.33R; dimensions: 13.5x10x5.2mm operating temperature: -25°C ~ 125°C; equivalent: D SDR1005-101KL

Equivalents

Any questions? We will be happy to answer.
Write sales // micros.com.pl or call: +48 785 054 437

Parameters

Dimensions:	13.5x10x5.2mm
Inductance:	100uH
Inductor type:	Power
Manufacturer:	N/A
Mounting:	SMD
Current:	1,2A
Resistance:	0,33 Ohm

All parameters





Add inquiry (RFQ)

Item available on request





Add inquiry (RFQ)

Item in delivery

Estimated date:
2025-02-01

Quantity of pcs.: 3000





Add inquiry (RFQ)

Item in delivery

Estimated date:
2025-03-10

Quantity of pcs.: 5000

• Parameters

Dimensions:	13.5x10x5.2mm
Inductance:	100uH
Inductor type:	Power
Manufacturer:	N/A
Mounting:	SMD
Current:	1,2A
Resistance:	0,33 Ohm
Operating temperature (range):	-25°C ~ 125°C
Tolerance:	20%

Equivalents

SDR1005-101KL Bourns Power inductor

Symbol Micros: SDR1005-101KL Bourns Power inductor Info Add to favourites Equivalents

Add inquiry (RFQ)

Item available on request
