FN 406-1-02 Schaffner Filter
Write sales // micros.com.pl or call: +48 785 054 437
| Inductance: | 12mH |
| Operating current: | 1A |
| Capacitance [Cx]: | 100nF |
| Body dimensions: | 45x15x28mm |
| Filter type: | Anti-Interference |
| Manufacturer: | Schaffner |
| Max. operating voltage: | 250V |
| Quantity of pcs. | 1+ | 3+ | 10+ | 20+ | 50+ |
|---|---|---|---|---|---|
| Net price (EUR) | 10,3237 | 9,7905 | 9,4522 | 9,3301 | 9,2173 |
| Quantity of pcs. | 250+ (Need a significantly larger quantity? Ask for price). |
|---|---|
| Net price (EUR) | 9,2173 |
| Quantity of pcs. | 1+ (Need a significantly larger quantity? Ask for price). |
|---|---|
| Net price (EUR) | 9,5447 |
| Quantity of pcs. | 250+ (Need a significantly larger quantity? Ask for price). |
|---|---|
| Net price (EUR) | 9,2173 |
| Inductance: | 12mH |
| Operating current: | 1A |
| Capacitance [Cx]: | 100nF |
| Body dimensions: | 45x15x28mm |
| Filter type: | Anti-Interference |
| Manufacturer: | Schaffner |
| Max. operating voltage: | 250V |
| Mounting: | THT |
| Operating temperature (range): | -25°C ~ 100°C |
Ultra Compact EMC Filter
Technical data:
Rated current: 1 A
Rated voltage: 250 VAC
Rated inductance: 12 mH(2x)
Capacitance, CX: 100 nF
Capacitance, CY: 2.2 nF(2x)
IEC-climate category: 25/100/21
Attenuation @ 150 MHz: 45 dB
Attenuation @ 10 MHz: 48 dB
Test voltage P/N-E: 2000 VAC
Dimensions L x W x H: 45 x 15 x 28 mm
Leakage current: <0.19 mA mA
Temperature range: -25...+100 °C
The FN 406 PCB filter is a single-phase filter designed for easy, fast and compact PCB- mounting. Choosing the FN 406 product line brings you the rapid availability of a standard filter associated with the necessary safety acceptance. Standard PCB singlephase filters are a practical solution helping you to pass EMI system approval in a short time. A selection on amperage ratings and medical types are designed to offer you the desired standard product.
Features and benefits:
• Good conducted attenuation performance, based on chokes with high saturation resistance and excellent thermal behavior
• PCB through hole mounting
• Low profile
• Custom specific versions on request
Typical applications:
Electrical and electronic equipment
Small to medium-sized machines and household equipment
Single-phase power supplies, switch-mode power supplies
Test and measurement equipment
Medical equipment
