HFW1V2818H220K EATON Power inductor

Symbol Micros: D HFW1V2818H220K

502942

D HFW1V2818H220K

Contractor Symbol:

Case : Rys.HFW1V28xxH

Datasheet

Add to favourites

SMD power inductor; inductance: 22uH; 10%; current:14A; resistance: 2,86mR; dimensions: 27,9x19,8x17,78mm

Parameters

Dimensions:	27,9x19,8x17,78mm
Inductance:	22uH
Inductor type:	Power
Manufacturer:	EATON
Mounting:	SMD
Current:	14A
Resistance:	2,86mOhm

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Dimensions:	27,9x19,8x17,78mm
Inductance:	22uH
Inductor type:	Power
Manufacturer:	EATON
Mounting:	SMD
Current:	14A
Resistance:	2,86mOhm
Tolerance:	10%
