IHLP2020CZERR82M01 Vishay Power inductor

Symbol Micros: D IHLP2020CZERR82M01

421699

D IHLP2020CZERR82M01

Contractor Symbol:

Case : Rys.IHLP2020CZ

Datasheet

Technical drawing Add to favourites

SMD power inductor; inductance: 0.82uH; 20%; current: 9.3A; resistance: 11.9mR; dimensions: 5,18x5,49x3mm; operating temperature: -55°C ~ 125°C

Parameters

Dimensions:	5.18x5.49x3mm
Inductance:	0,82uH
Inductor type:	Power
Manufacturer:	VISHAY
Mounting:	SMD
Current:	9,3A
Resistance:	0,0119 Ohm

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Dimensions:	5.18x5.49x3mm
Inductance:	0,82uH
Inductor type:	Power
Manufacturer:	VISHAY
Mounting:	SMD
Current:	9,3A
Resistance:	0,0119 Ohm
Operating temperature (range):	-55°C ~ 125°C
Tolerance:	20%
