LQG15HN7N5J02D Murata Inductor

Symbol Micros: D0402S0000.007/0.50A/0.24Rj

311850

D0402S0000.007/0.50A/0.24Rj

Contractor Symbol:

Case : Rys.LQG15

Datasheet

Technical drawing Add to favourites

Inductor; SMD0402; 7.5nH; 5%; 0.500A; 0.24R; 100MHz; operating temperature: -55°C~125°C

Parameters

Manufacturer:	MURATA
Mounting:	SMD
Case:	0402
Inductance:	7,5nH
Current:	0,5A
Resistance:	240 mOhm
Tolerance:	5%

All parameters

Manufacturer:: Murata Elektronik GmbH Manufacturer part number: LQG15HN7N5J02D Case style: Rys.LQG15

External warehouse:

90000 pcs.

Quantity of pcs.	10000+ (Need a significantly larger quantity? Ask for price).
Net price (EUR)	0,0074

Add to comparison tool Add inquiry (RFQ)

Packaging:
10000

Place an order

Delivery within 4-7 business days.
Minimum order amount
must exceed 20 Euro.

• Parameters

Manufacturer:	MURATA
Mounting:	SMD
Case:	0402
Inductance:	7,5nH
Current:	0,5A
Resistance:	240 mOhm
Tolerance:	5%
Operating temperature (range):	-55°C ~ 125°C
