LD05-23B15R2

Symbol Micros: DC LD05-23b15r2

331834

DC LD05-23b15r2

Contractor Symbol:

Case : MNd-25.4x25.4x17.6

Datasheet

Technical drawing Add to favourites

AC/DC Converter, 5W, Vout/Iout 15V/330mA, Viso 4000VAC, EFF 81%

Any questions? We will be happy to answer.
Write sales // micros.com.pl or call: +48 785 054 437

Parameters

Output current 1:	330mA
Power:	5W
Input voltage range:	85~305 (100~430VDC)
Secondary voltage 1:	15V
Insulation breakdown voltage:	4000V

All parameters

Manufacturer:: AMCHARD Manufacturer part number: LD05-23B15R2 RoHS Case style: MNd-25.4x25.4x17.6 Datasheet

In stock:

4 pcs.

Quantity of pcs.	1+	5+	20+	50+	200+
Net price (EUR)	4,3341	3,7268	3,4898	3,4047	3,3334

Add to comparison tool Add inquiry (RFQ)

Packaging:
5 Quantity (multiple: 1)

- +

• Parameters

Output current 1:	330mA
Power:	5W
Input voltage range:	85~305 (100~430VDC)
Secondary voltage 1:	15V
Insulation breakdown voltage:	4000V
