G2RL-1E-12DC power relay

Symbol Micros: P G2RL-1E-12DC

127796

P G2RL-1E-12DC

Contractor Symbol:

Case : Rys.G2RL

Datasheet

Technical drawing Add to favourites

12V; 16A; SPDT; 250mW; 29 x 12,5 x 15,7mm PCB

Any questions? We will be happy to answer.
Write sales // micros.com.pl or call: +48 785 054 437

Parameters

Contacts configuration:	SPDT
Coil voltage type [AC, DC]:	DC
Coil voltage (V):	12V
AC contact current:	16A
DC contact current:	16A
Contact voltage:	440VAC/300VDC
Coil power:	250mW

All parameters

Manufacturer:: OMRON Manufacturer part number: G2RL-1E-DC12 RoHS Case style: Rys.G2RL Datasheet

In stock:

155 pcs.

Quantity of pcs.	1+	5+	20+	100+	300+
Net price (EUR)	2,1892	1,7382	1,5691	1,4845	1,4587

Add to comparison tool Add inquiry (RFQ)

Packaging:
20/100 Quantity (multiple: 1)

- +

• Parameters

Contacts configuration:	SPDT
Coil voltage type [AC, DC]:	DC
Coil voltage (V):	12V
AC contact current:	16A
DC contact current:	16A
Contact voltage:	440VAC/300VDC
Coil power:	250mW
Mounting:	PCB
Manufacturer:	OMRON
Dimensions:	29 x 12,5 x 15,7mm
Operating temperature (range):	-40°C ~ 85°C
