HF115F/024-1Z1A power relay

Symbol Micros: P HF115f024-1z1a

191626

P HF115f024-1z1a

Contractor Symbol:

Case : Rys.JQX115F.3

Datasheet

Technical drawing Add to favourites

12A; 24V; SPDT; coil power 400mW; 29,0 x 12,7 x 15,7mm PCB; equivalent: RM85Z, RM83Z, AZ761, G2RL; AgSnO2

Any questions? We will be happy to answer.
Write sales // micros.com.pl or call: +48 785 054 437

Parameters

Coil voltage (V):	24V
Insulation breakdown voltage:	5000V
Contact current:	12A
Type:	SPDT
Coil current type:	DC

All parameters

Manufacturer:: Hongfa Manufacturer part number: HF115F/024-1Z1A RoHS Case style: Rys.JQX115F.3 Datasheet

In stock:

450 pcs.

Quantity of pcs.	1+	5+	20+	100+	300+
Net price (EUR)	1,8298	1,3577	1,1862	1,1017	1,0758

Add to comparison tool Add inquiry (RFQ)

Packaging:
20/1000 Quantity (multiple: 1)

- +

• Parameters

Coil voltage (V):	24V
Insulation breakdown voltage:	5000V
Contact current:	12A
Type:	SPDT
Coil current type:	DC
