N4100-CBS 24VDC signal relay

Symbol Micros: P N4100CBS5-24

76787

P N4100CBS5-24

Contractor Symbol:

Case : Rys.4100

Datasheet

Technical drawing Add to favourites

5A; 24V; SPDT; coil power 450mW; 15,5 x 11 x 11,5mm PCB

Any questions? We will be happy to answer.
Write sales // micros.com.pl or call: +48 785 054 437

Parameters

Contacts configuration:	SPDT
Coil voltage type [AC, DC]:	DC
Coil voltage (V):	24V
AC contact current:	5A
DC contact current:	5A
Contact voltage:	220VAC/60VDC
Coil power:	450mW

All parameters

Manufacturer:: Forward Relays Manufacturer part number: N4100CBS5DC24V0.45 RoHS Case style: Rys.4100 Datasheet

In stock:

15 pcs.

Quantity of pcs.	1+	5+	25+	100+	400+
Net price (EUR)	1,1894	0,8328	0,6947	0,6464	0,6257

Add to comparison tool Add inquiry (RFQ)

Packaging:
25/100 Quantity (multiple: 1)

- +

Manufacturer:: Forward Relays Manufacturer part number: N4100CBS5DC24C RoHS Case style: Rys.4100 Datasheet

In stock:

20 pcs.

Quantity of pcs.	1+	5+	25+	100+	400+
Net price (EUR)	1,1894	0,8328	0,6947	0,6464	0,6257

Add to comparison tool Add inquiry (RFQ)

Packaging:
25/100 Quantity (multiple: 1)

- +

• Parameters

Contacts configuration:	SPDT
Coil voltage type [AC, DC]:	DC
Coil voltage (V):	24V
AC contact current:	5A
DC contact current:	5A
Contact voltage:	220VAC/60VDC
Coil power:	450mW
Mounting:	PCB
Manufacturer:	NFR
Dimensions:	15,5 x 11 x 11,5mm
Operating temperature (range):	-25°C ~ 70°C
