NT76-CS 12VDC power relay

Symbol Micros: P NT76-CS-12C

93838

P NT76-CS-12C

Contractor Symbol:

Case : Rys.NT76

Datasheet

Technical drawing Add to favourites

16A; 12V; SPDT; coil power 450mW; 22,3 x 16,6 x 11mm; sealed PCB; contacts AgCdO

Any questions? We will be happy to answer.
Write sales // micros.com.pl or call: +48 785 054 437

Parameters

Type:	SPDT
Coil current type:	DC
Coil voltage (V):	12V
Contact current:	16A
Insulation breakdown voltage:	1500V

All parameters

Manufacturer:: Forward Relays Manufacturer part number: NT76-C-S-12VDC RoHS Case style: Rys.NT76 Datasheet

In stock:

45 pcs.

Quantity of pcs.	1+	5+	25+	100+	400+
Net price (EUR)	1,4397	1,0064	0,8410	0,7827	0,7571

Add to comparison tool Add inquiry (RFQ)

Packaging:
25/100 Quantity (multiple: 1)

- +

• Parameters

Type:	SPDT
Coil current type:	DC
Coil voltage (V):	12V
Contact current:	16A
Insulation breakdown voltage:	1500V
