Single turn shaft potentiometer; 5K

Symbol Micros: PO R16148-1B-2-A5K

114054

PO R16148-1B-2-A5K

Contractor Symbol:

Case : Rys.R16148-1B-2

Datasheet

Technical drawing Add to favourites

PCB; logarithmic characteristics; 17x11.5mm; shaft diameter: 6mm; power: 0.125W; tolerance: 20%; max.V=200V; operating temperature: -10°C÷70°C

Parameters

Resistance:	5,0kOhm
Dimensions:	17x11.5mm
Power:	125mW
Operating temperature (range):	-10°C ~ 70°C
Manufacturer:	N/A
Tolerance:	20%
Mounting:	PCB

All parameters

Manufacturer:: PASSIVE TECH Manufacturer part number: WH148-1B-2-A 5kR RoHS Case style: Rys.WH148-1B-2

In stock:

2 pcs.

Quantity of pcs.	3+	20+	100+	500+	2000+
Net price (EUR)	0,3046	0,1629	0,1268	0,1148	0,1110

Add inquiry (RFQ)

Packaging:
100/500 Quantity (multiple: 1)

- +

• Parameters

Resistance:	5,0kOhm
Dimensions:	17x11.5mm
Power:	125mW
Operating temperature (range):	-10°C ~ 70°C
Manufacturer:	N/A
Tolerance:	20%
Mounting:	PCB
Characteristic:	Logarithmic
Type of potentiometer:	Shaft
Kind of potentiometer:	Single-turn
