BS09GB SAB Dip-switch

Symbol Micros: PRZ Dip09su

63253

PRZ Dip09su

Contractor Symbol:

Case : Rys.dwsDIP9s

Datasheet

Technical drawing Add to favourites

slide, 9 contacts; THT; blue color; gold plating 1u", height 5.20mm + knob 1.10mm; eqiv. DS-09, EDG09S; EDG109S

Any questions? We will be happy to answer.
Write sales // micros.com.pl or call: +48 785 054 437

Parameters

Overall length:	23,86mm
Number of sections:	9
Manufacturer:	SAB
Mechanical durability:	5000 cycles
Colour:	Blue
Type of slider:	Raised
Mounting:	THT

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Overall length:	23,86mm
Number of sections:	9
Manufacturer:	SAB
Mechanical durability:	5000 cycles
Colour:	Blue
Type of slider:	Raised
Mounting:	THT
Terminal pitch:	2,54mm
