Handle selector switch; N/O+N/O

Symbol Micros: PRZ LAY5-ED53

216455

PRZ LAY5-ED53

Contractor Symbol:

Case : Rys.LAY5-ED53

Datasheet

Technical drawing Add to favourites

Handle selector switch; black; 3 positions; flush; spring return; N/O+N/O; one button; current: 10A; dimensions: 70x29mm

Parameters

Dimensions:	70x29mm
Button colour:	Black
Contacts configuration:	N/O+N/O
Accessories type:	N/A
Diameter:	29mm
Illumination:	None
Button shape:	Feather

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Dimensions:	70x29mm
Button colour:	Black
Contacts configuration:	N/O+N/O
Accessories type:	N/A
Diameter:	29mm
Illumination:	None
Button shape:	Feather
Number of holes:	N/A
Button type:	Covered
Number of buttons:	1
Manufacturer:	N/A
