Wire wound resistor; 2.2kR

Symbol Micros: R dr100/K002.20j

98620

R dr100/K002.20j

Contractor Symbol:

Case : Rys.REZDr010WRad

Datasheet

Technical drawing Add to favourites

Wire wound resistor; 2,2kR; 5%; 10W; with heatsink; screwed; dimensions: 20x23x10.5mm

Parameters

Resistance:	2,2 kOhm
Power:	10W
Tolerance:	5%
Mounting:	Screw
Dimensions:	20x23x10.5mm
Resistor type:	Wire-wound

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Resistance:	2,2 kOhm
Power:	10W
Tolerance:	5%
Mounting:	Screw
Dimensions:	20x23x10.5mm
Resistor type:	Wire-wound
