AOD2544

Symbol Micros: TAOD2544

131057

TAOD2544

Contractor Symbol:

Case : TO252 (DPACK)

Datasheet

Technical drawing Add to favourites

Transistor N-Channel MOSFET; 150V; 20V; 107mOhm; 23A; 75W; -55°C ~ 175°C;

Parameters

Open channel resistance:	107mOhm
Max. drain current:	23A
Max. power loss:	75W
Case:	TO252 (DPACK)
Manufacturer:	ALPHA&OMEGA
Max. drain-source voltage:	150V
Transistor type:	N-MOSFET

All parameters

Manufacturer:: ALPHA&OMEGA Manufacturer part number: AOD2544 RoHS Case style: TO252 (DPACK) t/r Datasheet

In stock:

55 pcs.

Quantity of pcs.	1+	3+	10+	50+	200+
Net price (EUR)	0,9551	0,7004	0,5636	0,4835	0,4552

Add to comparison tool Add inquiry (RFQ)

Packaging:
50 Quantity (multiple: 1)

- +

Manufacturer:: ALPHA&OMEGA Manufacturer part number: AOD2544 Case style: TO252 (DPACK)

External warehouse:

2500 pcs.

Quantity of pcs.	2500+ (Need a significantly larger quantity? Ask for price).
Net price (EUR)	0,4552

Add to comparison tool Add inquiry (RFQ)

Packaging:
2500

Place an order

Delivery within 4-7 business days.
Minimum order amount
must exceed 20 Euro.

• Parameters

Open channel resistance:	107mOhm
Max. drain current:	23A
Max. power loss:	75W
Case:	TO252 (DPACK)
Manufacturer:	ALPHA&OMEGA
Max. drain-source voltage:	150V
Transistor type:	N-MOSFET
Max. gate-source Voltage:	20V
Operating temperature (range):	-55°C ~ 175°C
Mounting:	SMD
