VN20.6/09465 MARSCHNER Encapsulated transformer

Symbol Micros: TR Z00.35/06b MAR
Contractor Symbol:
Case : Rys.VN20.6
Technical drawing Add to favourites
Encapsulated transformer; 0.35VA; 230V/6V; 58mA; Ta=70°C; H=15mm; equivalent: BV 201 0128; TR Z00.35/06b II
Parameters
VA power: 0,35VA
Input voltage: 230V
Secondary voltage 1: 6V
Thermal class: 70°C
Mounting: PCB
Transformator type: Encapsulated transformer
Manufacturer: MARSCHNER


Item available on request
VA power: 0,35VA
Input voltage: 230V
Secondary voltage 1: 6V
Thermal class: 70°C
Mounting: PCB
Transformator type: Encapsulated transformer
Manufacturer: MARSCHNER
Secondary winding current 1: 58mA
