AM1D-0515D-NZ

Symbol Micros: UIAM1D0515dnz

43393

UIAM1D0515dnz

Contractor Symbol:

Case : Rys.AM1D-xxxxDN

Datasheet

Technical drawing Add to favourites

1W DC-DC Converter, Dual, Vin 5V, Vout +-15V, +-35mA, 1000VDC, EFF79%

Product description

Any questions? We will be happy to answer.
Write sales // micros.com.pl or call: +48 785 054 437

Parameters

Output current:	35mA
Power:	1W
Output voltage range [V]:	+- 15V
Input voltage:	5V
Insulation breakdown voltage:	1000V

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters
• Description

Output current:	35mA
Power:	1W
Output voltage range [V]:	+- 15V
Input voltage:	5V
Insulation breakdown voltage:	1000V

Detailed description

Micros Part Number

UIAM1D0515dnz

Manufacturer Part Number

AM1D-0515D-NZ

Wattage

1W

Max output current

±0.035A

Output Type

Dual

Input Voltage

4.5~5.5VDC

Output Voltage

15V, -15V, ±5%

Input Output Isolation (VDC)

1K

Package

SIP7

Temperature range

-40°C to +85°C
