DBE2-0514 PAIRUI

Symbol Micros: UIAM2S0515sz c

101216

UIAM2S0515sz c

Contractor Symbol:

Case : Rys.AM1SxxxxS

Datasheet

Technical drawing Add to favourites

DC-DC Converter; Isolated; Single Output; 2W; 133mA; 15V; 1,5kV; 4,5V~5,5V; -40°C~85°C; EFF 84%; Substitute: AM2S-0515SZ;

Any questions? We will be happy to answer.
Write sales // micros.com.pl or call: +48 785 054 437

Parameters

Input voltage range:	4,5V ~ 5,5V
Output current:	133mA
Output voltage range [V]:	15V
Efficiency:	84%
Power:	2,0W
Input voltage:	5V
Output current 1:	133mA

All parameters

Manufacturer:: PAIRUI Manufacturer part number: DBE2-0514 RoHS Case style: Rys.AM1SxxxxS Datasheet

In stock:

5 pcs.

Quantity of pcs.	1+	3+	10+	30+	100+
Net price (EUR)	3,4365	3,0537	2,8258	2,7107	2,6426

Add to comparison tool Add inquiry (RFQ)

Packaging:
10 Quantity (multiple: 1)

- +

• Parameters

Input voltage range:	4,5V ~ 5,5V
Output current:	133mA
Output voltage range [V]:	15V
Efficiency:	84%
Power:	2,0W
Input voltage:	5V
Output current 1:	133mA
Output voltage:	15V
Insulation breakdown voltage:	1500V
Secondary voltage 1:	15V
