DAE2-1211H

Symbol Micros: UIDAE21211H

370920

UIDAE21211H

Contractor Symbol:

Case : Rys.AM2D-xxxxSH40Z

Datasheet

Technical drawing Add to favourites

2W DC-DC Conv; Unregulated, 6KVDC; Vin 12V; Vout 5V; 40°C~85°C; Substitute: PAIRUI DAE2-1211H, TPPOWER TPK1205SA; AM2D-1205SH40Z;

Any questions? We will be happy to answer.
Write sales // micros.com.pl or call: +48 785 054 437

Parameters

Input voltage range:	10,8V ~ 13,2V
Output current:	0,4A
Output voltage range [V]:	15V
Efficiency:	75%
Power:	2,0W
Input voltage:	12V
Output voltage:	5V

All parameters

Manufacturer:: PAIRUI Manufacturer part number: DAE2-1211H RoHS Case style: Rys.AM2D-xxxxSH40Z Datasheet

In stock:

10 pcs.

Quantity of pcs.	1+	3+	10+	30+	100+
Net price (EUR)	4,6412	4,1265	3,8163	3,6612	3,5696

Add to comparison tool Add inquiry (RFQ)

Packaging:
10 Quantity (multiple: 1)

- +

• Parameters

Input voltage range:	10,8V ~ 13,2V
Output current:	0,4A
Output voltage range [V]:	15V
Efficiency:	75%
Power:	2,0W
Input voltage:	12V
Output voltage:	5V
Insulation breakdown voltage:	6000V
