MBI5124GF

Symbol Micros: UIMBI5124gf

134329

UIMBI5124gf

Contractor Symbol:

Case :

Datasheet

Technical drawing Add to favourites

LED Display Driver, Ghosting Elimination 16 channels, Iout 1÷25mA @ 5V, Vds 17V max, fCLK 25MHz, Vdd 4.5÷5.5V, -40÷85°C

Any questions? We will be happy to answer.
Write sales // micros.com.pl or call: +48 785 054 437

Parameters

Controller type:	SIPO Shift Register
Driver application:	LED Matrix
Number of channels:	16
Output current / canal [mA]:	1mA ~ 25mA @ 5V
Output voltage:	17V
Supply voltage range:	3V ~ 5,5V
Operating temperature (range):	-40°C ~ 85°C

All parameters

Manufacturer:: MACROBLOK Manufacturer part number: MBI5124GF RoHS Case style: SOP24B t/r Datasheet

In stock:

20 pcs.

Quantity of pcs.	2+	10+	30+	100+	400+
Net price (EUR)	0,6602	0,4141	0,3451	0,3060	0,2876

Add to comparison tool Add inquiry (RFQ)

Packaging:
100 Quantity (multiple: 1)

- +

• Parameters

Controller type:	SIPO Shift Register
Driver application:	LED Matrix
Number of channels:	16
Output current / canal [mA]:	1mA ~ 25mA @ 5V
Output voltage:	17V
Supply voltage range:	3V ~ 5,5V
Operating temperature (range):	-40°C ~ 85°C
Case:	SOP24B
