HD D-Sub connector CONNECTAR

Symbol Micros: Z DKG26W9

21586

Z DKG26W9

Contractor Symbol:

Case : Rys.DKG26W9

Datasheet

Add to favourites

male; 25pin; for PCB; angled; HD; thread insert 4-40UNC, with boardlock, metal housing; gold plated contacts, black insulator, eqiv. DMR26M-HD

Any questions? We will be happy to answer.
Write sales // micros.com.pl or call: +48 785 054 437

Parameters

Colour:	Black
Number of pins:	26
Manufacturer:	CONNECTAR
Type of connector:	Plug
Orientation:	Angled

All parameters

Manufacturer:: CONNECTAR Manufacturer part number:   Case style: Rys.DKG26W9 Datasheet

In stock:

32 pcs.

Quantity of pcs.	1+	5+	40+	200+	400+
Net price (EUR)	0,8901	0,5926	0,4635	0,4312	0,4243

Add to comparison tool Add inquiry (RFQ)

Packaging:
40 Quantity (multiple: 1)

- +

Manufacturer:: CONNECTAR Manufacturer part number:   Case style: Rys.DKG26W9 Datasheet

In stock:

160 pcs.

Quantity of pcs.	1+	5+	20+	80+	400+
Net price (EUR)	0,8901	0,5926	0,4889	0,4451	0,4243

Add to comparison tool Add inquiry (RFQ)

Packaging:
80 Quantity (multiple: 1)

- +

• Parameters

Colour:	Black
Number of pins:	26
Manufacturer:	CONNECTAR
Type of connector:	Plug
Orientation:	Angled
