DS1018-242BX CONNFLY IDC connector

Symbol Micros: Z MP24

116923

Z MP24

Contractor Symbol:

Case : Rys.MP24

Datasheet

Technical drawing Add to favourites

male 16pin IDC, pitch 2.54mm, black, with fastener, for ribbon cable 28AWG suitable for IDC cable mounting for PCB, eqiv. MM-PCT24, AWLP24, PCT24-LF

Any questions? We will be happy to answer.
Write sales // micros.com.pl or call: +48 785 054 437

Parameters

Number of pins:	16
Mounting:	Tape mounting (AWG28)
Terminal pitch:	2,54mm
Gold plating:	Gilded contacts
Type of connector:	Male

All parameters

Manufacturer:: CONNFLY (Zhenqin) Manufacturer part number: DS1018-242BX RoHS Case style: Rys.MP24

In stock:

874 pcs.

Quantity of pcs.	2+	15+	84+	420+	900+
Net price (EUR)	0,4444	0,2464	0,1973	0,1814	0,1780

Add to comparison tool Add inquiry (RFQ)

Packaging:
84/900 Quantity (multiple: 1)

- +

• Parameters

Number of pins:	16
Mounting:	Tape mounting (AWG28)
Terminal pitch:	2,54mm
Gold plating:	Gilded contacts
Type of connector:	Male
