SP2112/P2-1N WEIPU Industrial connector

Symbol Micros: Z SP2112/P2

78735

Z SP2112/P2

Contractor Symbol:

Case : Rys.Z SP2112/P2

Datasheet

Technical drawing Add to favourites

Male connector, circular, 2pin screwed, for panel mounting, IP68, 500V, 30A, mate with SP2110; external thread;

Parameters

Series:	SP21
Number of pins:	2
Current:	30A
Operating voltage:	500V
Manufacturer:	WEIPU
Mounting:	Soldering
Connector:	Socket

All parameters

Manufacturer:: WEIPU CONNECTOR Manufacturer part number: SP2112/P2-GW RoHS Case style: Rys.Z SP2112/P2 Datasheet

In stock:

5 pcs.

Quantity of pcs.	1+	3+	10+	30+	100+
Net price (EUR)	3,9361	3,4998	3,2376	3,1064	3,0278

Add to comparison tool Add inquiry (RFQ)

Packaging:
10 Quantity (multiple: 1)

- +

Manufacturer:: WEIPU CONNECTOR Manufacturer part number: SP2112/P2-1N RoHS Case style: Rys.Z SP2112/P2 Datasheet

In stock:

10 pcs.

Quantity of pcs.	1+	3+	10+	30+	100+
Net price (EUR)	3,9361	3,4998	3,2376	3,1064	3,0278

Add to comparison tool Add inquiry (RFQ)

Packaging:
10 Quantity (multiple: 1)

- +

• Parameters

Series:	SP21
Number of pins:	2
Current:	30A
Operating voltage:	500V
Manufacturer:	WEIPU
Mounting:	Soldering
Connector:	Socket
IP rating:	IP68
Type of connector:	Male
