SP2112/S5-1N WEIPU Industrial connector

Symbol Micros: Z SP2112/S5

74662

Z SP2112/S5

Contractor Symbol:

Case : Rys.Z SP2112/S5

Datasheet

Technical drawing Add to favourites

Female connector, circular, 5pin; screwed, for panel mounting, IP68, 500V, 30A, mate with SP2110; external thread;

Parameters

Series:	SP21
Number of pins:	5
Current:	30A
Operating voltage:	500V
Manufacturer:	WEIPU
Mounting:	Soldering
Connector:	Socket

All parameters

Manufacturer:: WEIPU CONNECTOR Manufacturer part number: SP2112/S5-1N RoHS Case style: Rys.Z SP2112/S5 Datasheet

In stock:

70 pcs.

Quantity of pcs.	1+	3+	10+	30+	100+
Net price (EUR)	3,9647	3,5237	3,2590	3,1279	3,0492

Add to comparison tool Add inquiry (RFQ)

Packaging:
10 Quantity (multiple: 1)

- +

• Parameters

Series:	SP21
Number of pins:	5
Current:	30A
Operating voltage:	500V
Manufacturer:	WEIPU
Mounting:	Soldering
Connector:	Socket
IP rating:	IP68
Type of connector:	Female
