XY2500V-F(3.5)-04P (black) XINYA Terminal block

Symbol Micros: Z TLPHC001v-04p-bk

497827

Z TLPHC001v-04p-bk

Contractor Symbol:

Case : Rys.TLPHC001v-04p

Datasheet

Technical drawing Add to favourites

4 poles; pitch: 3.5mm; height: 9.1mm; black color, 300V; 8A, straight, mates with TLPS001 / TLPSZ001 3.5mm solder pin: brass, tin plated; eqiv. MCV 1,5/ 4-G-3,5; 1843622; 15EDGVC-3.5-04P

Any questions? We will be happy to answer.
Write sales // micros.com.pl or call: +48 785 054 437

Parameters

Height:	9,1mm
Number of pins:	4
Terminal pitch:	3,5mm
Colour:	Black
Manufacturer:	XINYA

All parameters

Manufacturer:: XINYA Manufacturer part number: XY2500V-F-4P 3.5mm Black RoHS Case style: Rys.TLPHC001v-04p Datasheet

In stock:

2800 pcs.

Quantity of pcs.	5+	20+	100+	400+	1600+
Net price (EUR)	0,2179	0,1099	0,0660	0,0532	0,0484

Add inquiry (RFQ)

Packaging:
400 Quantity (multiple: 1)

- +

Manufacturer:: XINYA Manufacturer part number: XY2500V-F-4P 3.5mm Black RoHS Case style: Rys.TLPHC001v-04p Datasheet

In stock:

200 pcs.

Quantity of pcs.	5+	30+	200+	1000+	4000+
Net price (EUR)	0,2179	0,0947	0,0593	0,0508	0,0484

Add to comparison tool Add inquiry (RFQ)

Packaging:
200 Quantity (multiple: 1)

- +

• Parameters

Height:	9,1mm
Number of pins:	4
Terminal pitch:	3,5mm
Colour:	Black
Manufacturer:	XINYA
