XY2500V-D(5.08)-04P (black) XINYA Terminal block

Symbol Micros: Z TLPHC300v-04p-bk

497802

Z TLPHC300v-04p-bk

Contractor Symbol:

Case : Rys.TLPHC300v-04p

Datasheet

Technical drawing Add to favourites

4 poles; pitch: 5.08mm; height 12mm; black colour; close, 300V; 15A; straigth, mates with TLPS 5.08mm solder pin: brass; tin plated; equivalent: MSTBVA 2.5/ 4-G-5.08; 1755752; 2EDGVC-5.08-04P

Any questions? We will be happy to answer.
Write sales // micros.com.pl or call: +48 785 054 437

Parameters

Height:	12,0mm
Number of pins:	4
Colour:	Black
Manufacturer:	XINYA
Terminal pitch:	5,08mm

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Height:	12,0mm
Number of pins:	4
Colour:	Black
Manufacturer:	XINYA
Terminal pitch:	5,08mm
